95MW Solar Farm
Tailem Bend Solar Farm is a 100MW solar photovoltaic generation station that feeds to the National Grid via the ElectraNet’s Transmission system. Over 350,000 solar panels feed into Inverter Stations with step up power transformers, interconnected via Ring Main Units (RMUs) across the solar farm reticulation system. The reticulation system feeds into 6 high voltage feeders across two Switchboards before feeding into the ElectraNet transmission substation at Tailem Bend.
- Owner: Decmil Australia
- Location: Sunraysia, NSW
- Scope: 22kV & 132kV Testing and Commissioning
SERVICES PROVIDED
Integral Power® was engaged by Decmil to provide High Voltage Testing and Commissioning of the entire AC network assets including:
- Primary Testing of High Voltage Switchboards
- Primary Testing of 2 x 33kV High Voltage Switchboards
- Primary & Secondary Injection Testing of the Solar Farm Protection Schemes
- Off Frequency Current Injection Testing of the 33kV & 220kV Earth Grids
- Step and Touch Potential Validation at the 33kV and 220kV Substations
- Site Acceptance Testing of 104 x 2.2MVA, 0.6/33kV Power Transformers
- Detailed Functional and Wiring Checks
- SCADA Integration Testing
- High Voltage Switching and Back Energisation Services
